150W DC-DC Boost Converter 10-32V to 12-35V Step-Up Power Supply Module
150W DC-DC Boost Converter 10-32V to 12-35V Step-Up Power Supply Module Key Features: Type: Non-isolated Step-Up (Boost) Converter. Input Voltage: DC 10-32V. Output Voltage: DC 12-35V, adjustable with CV (Constant Voltage) feature. (Note: This module does not include CC, or Constant Current, adjustment.) Maximum Output Power: 100W under natural cooling, and up to 150W with enhanced cooling. Output Current: Up to 10A (Note: This current is not adjustable as the module lacks CC adjustment). Efficiency: Approximately 94% (varies with different input and output configurations). Output Ripple: 350mV under typical conditions. Working Temperature: Industrial grade, operational from -40°C to +85°C. (Note: Above 40°C, power reduction or enhanced cooling is recommended.) No-Load Current: Typically around 20mA. Dynamic Response Speed: 300uS ± 5%. Protection: Note that this module does not have short-circuit protection or input reverse protection. Users should implement these protections separately. Size: 65 x 47 x 23.5 mm. Applications: DIY adjustable vehicle power supply (output voltage can’t be lower than input voltage). Boost charger for devices like laptops. Power supply for solar battery chargers. Pre-supply system for various electronic equipment. Adjustment Instructions: Voltage adjustment is done via a blue potentiometer. Rotate clockwise to increase voltage, counterclockwise to decrease. Use a multimeter to monitor voltage changes during adjustment. If output voltage is stuck at input voltage level, turn the potentiometer counterclockwise for at least 20 turns. Package Includes: 1 x 150W DC-DC Boost Converter Module (10-32V to 12-35V).
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | Unbranded |
| MPN | Does Not Apply |
150W DC-DC Boost Converter 10-32V to 12-35V Step-Up Power Supply Module Key Features: Type: Non-isolated Step-Up (Boost) Converter. Input Voltage: DC 10-32V. Output Voltage: DC 12-35V, adjustable with CV (Constant Voltage) feature. (Note: This module does not include CC, or Constant Current, adjustment.) Maximum Output Power: 100W under natural cooling, and up to 150W with enhanced cooling. Output Current: Up to 10A (Note: This current is not adjustable as the module lacks CC adjustment). Efficiency: Approximately 94% (varies with different input and output configurations). Output Ripple: 350mV under typical conditions. Working Temperature: Industrial grade, operational from -40°C to +85°C. (Note: Above 40°C, power reduction or enhanced cooling is recommended.) No-Load Current: Typically around 20mA. Dynamic Response Speed: 300uS ± 5%. Protection: Note that this module does not have short-circuit protection or input reverse protection. Users should implement these protections separately. Size: 65 x 47 x 23.5 mm. Applications: DIY adjustable vehicle power supply (output voltage can’t be lower than input voltage). Boost charger for devices like laptops. Power supply for solar battery chargers. Pre-supply system for various electronic equipment. Adjustment Instructions: Voltage adjustment is done via a blue potentiometer. Rotate clockwise to increase voltage, counterclockwise to decrease. Use a multimeter to monitor voltage changes during adjustment. If output voltage is stuck at input voltage level, turn the potentiometer counterclockwise for at least 20 turns. Package Includes: 1 x 150W DC-DC Boost Converter Module (10-32V to 12-35V).
