2-2-2-4 Aluminum Mobile Home Feeder Direct Burial Cable (100 Amp) 600V
HomeView All ListingsStore PoliciesNewsletterFeedbackContact Us Store Categories Aluminum URD Cable Aluminum Service Drop Cable Aluminum XHHW Aluminum XLP USE Aluminum SER Alpha Wire Belden Cable Bus Drop Cable Copper SER Copper XHHW Copper XLP USE Diesel Locomotive Cable Festoon Cable Fire Alarm Cable High Temperature Wire Jumper Cable Mining Cable Type G & GG-C Thermostat Cable Power Power Cable NM-B Wire Security Fire Alarm Cable SIS Switchboard Wire Solar Photovoltaic PV Wire Stage Lighting Cable Submersible Pump Cable THHN THWN-2 Copper Wire Tray Cable Type W Power Cable UF-B Cable Welding Cable 2-2-2-4 Aluminum Mobile Home Feeder Direct Burial Cable 600V Click Thumbnails to Enlarge APPLICATION • 2-2-2-4 Mobile Home Feeder cable is designed for mobile homes as a service entrance cable. The cable is sunlight resistant and is approved for use in accordance with the recommendations of the National Electric Code in raceways and underground installations. Maximum operating temperature is not to exceed 90°C in wet and dry locations. Voltage rating is 600 volts. CONDUCTOR • Compact Stranded AA-8000 Series Aluminum Conductor, per ASTM B-800 & B-801 INSULATION • Type USE-2/RHH/RHW-2 Cross-Linked Polyethylene (XLP) insulation. ASSEMBLY • It has Four Conductors including two phase conductors, one neutral and one ground. The neutral conductor is identified by three continuous white longitudinal stripes. The grounding conductor is identified by total green surface coating STANDARDS • UL 44 for Type RHH or RHW-2 • UL 854 for Type USE-2 Insulated Wire • National Electrical Code NFPA 70 (NEC) • ICEA S-95-658/NEMA WC-70 DISCLAIMER • Picture May Not Represent Actual Cable and Is Only Used As A Representation Please Refer to The Specifications For Product Accuracy. PRODUCT SPECIFICATIONS Phase Conductor Size 2 AWG Neutral Conductor Size 2 AWG Ground Conductor Size 4 AWG Insulation Thickness (inches) 0.060 Overall Diameter (inches) 0.909 Ampacity 100 Amps Weight (Lbs/1000ft) 345 Shipping Need the wire fast? Ask about our expedited shipping to get it to you on time. Signature required for all deliveries. Please note eBay's delivery dates are only estimates actual delivery dates may be faster or longer, please message us for exact delivery times.*** Payment & Returns ***All returns must be made within 30 days from the date of purchase or they will not be accepted. Nassau National Cable does not cover re-delivery fees, extraneous shipping expenses or change of address fees after shipping***
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Sheath Color | Black |
| Brand | Nassau |
| Wire Style | Stranded |
| Voltage | 600 V |
| Current Rating | 100 A |
| Conductor Material | Aluminum |
| Country/Region Of Manufacture | United States |
| Wire Gauge | 2 AWG (6.5 mm) |
