7.5 HP SINGLE PHASE 40 AMP MAGNETIC STARTER CONTROL ELECTRIC MOTOR
BRAND NEW!! For use on 7.5 HP Motors w/ 1 phase power 220 - 240VAC THIS IS A BRAND NEW IN THE BOX 7.5HP SINGLE PHASE MAGNETIC MOTOR STARTER. THIS STARTER COMES EQUIPPED WITH AN ADJUSTABLE OVERLOAD RELAY. SIMPLY TURN THE DIAL TO YOUR REQUIRED AMPS FOR YOUR APPLICATION. THE AMP DIAL RANGE IS BETWEEN 32 - 48 AMPS. ALSO COMES WITH BUILT IN SIDE MOUNTED AUXILIARY CONTACTS. NORMALLY OPEN & NORMALLY CLOSED TYPE. STARTER COMES COMPLETE IN A METAL NEMA 1 ENCLOSURE, IN ADDITION TO 4 PUNCH OUTS FOR INCOMING AND OUTGOING WIRES. MANUFACTURER HAS SUPPLIED 4 RUBBER GROMMETS FOR WIRE PROTECTION. RESET BUTTON LOCATED ON THE OVERLOAD. RESET CAN BE SET TO MANUAL OR AUTO RESET. HP: 7.5 VOLTAGE: 220-240 AMPS: 40 AMP CONTACTOR PHASE: SINGLE ENCLOSURE: NEMA SIZE 1 ENCLOSURE DIMENSIONS: 8.75" Tall 5.2" wide 5.5 Depth OVERLOAD: AMPERAGE DIAL BETWEEN 32-48 AMPS WIRING DIAGRAM INCLUDED. CONTACT US FOR ADDITIONAL WIRING INSTRUCTIONS.FOR AIR COMPRESSOR APPLICATIONS WITH PRESSURE SWITCH. YOU HAVE 2 OPTIONS TO CONNECT YOUR LEADS FROM THE PRESSURE SWITCH/TOGGLE SWITCH. L1 & #14 AUX CONTACT PORT OR L1 & COIL TERMINAL A2EITHER OPTION WILL GIVE YOU THE SAME RESULT VISIT OUR STORE FOR THE BEST PRICE ON ELECTRIC MOTORS. PLEASE CONTACT US WITH ANY QUESTIONS OR INQUIRIES ABOUT OUR PRODUCTS.
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Refund Will Be Given As | Money Back |
| MPN | Does Not Apply |
| Country/Region Of Manufacture | Unknown |
| Brand | Unbranded/Generic |
BRAND NEW!! For use on 7.5 HP Motors w/ 1 phase power 220 – 240VAC THIS IS A BRAND NEW IN THE BOX 7.5HP SINGLE PHASE MAGNETIC MOTOR STARTER. THIS STARTER COMES EQUIPPED WITH AN ADJUSTABLE OVERLOAD RELAY. SIMPLY TURN THE DIAL TO YOUR REQUIRED AMPS FOR YOUR APPLICATION. THE AMP DIAL RANGE IS BETWEEN 32 – 48 AMPS. ALSO COMES WITH BUILT IN SIDE MOUNTED AUXILIARY CONTACTS. NORMALLY OPEN & NORMALLY CLOSED TYPE. STARTER COMES COMPLETE IN A METAL NEMA 1 ENCLOSURE, IN ADDITION TO 4 PUNCH OUTS FOR INCOMING AND OUTGOING WIRES. MANUFACTURER HAS SUPPLIED 4 RUBBER GROMMETS FOR WIRE PROTECTION. RESET BUTTON LOCATED ON THE OVERLOAD. RESET CAN BE SET TO MANUAL OR AUTO RESET. HP: 7.5 VOLTAGE: 220-240 AMPS: 40 AMP CONTACTOR PHASE: SINGLE ENCLOSURE: NEMA SIZE 1 ENCLOSURE DIMENSIONS: 8.75″ Tall 5.2″ wide 5.5 Depth OVERLOAD: AMPERAGE DIAL BETWEEN 32-48 AMPS WIRING DIAGRAM INCLUDED. CONTACT US FOR ADDITIONAL WIRING INSTRUCTIONS.FOR AIR COMPRESSOR APPLICATIONS WITH PRESSURE SWITCH. YOU HAVE 2 OPTIONS TO CONNECT YOUR LEADS FROM THE PRESSURE SWITCH/TOGGLE SWITCH. L1 & #14 AUX CONTACT PORT OR L1 & COIL TERMINAL A2EITHER OPTION WILL GIVE YOU THE SAME RESULT VISIT OUR STORE FOR THE BEST PRICE ON ELECTRIC MOTORS. PLEASE CONTACT US WITH ANY QUESTIONS OR INQUIRIES ABOUT OUR PRODUCTS.
