CH120 Eaton Circuit Breaker Type CH 1 Pole 20 Amp 3/4in 120v Eaton Circuit
CH120 Eaton Circuit Breaker Type CH 1 Pole 20 Amp 3/4in 120v Eaton Circuit. Recommended for use with type CH load centers Works for up to 2,200-watt applications Ideal for protecting the wires from overheating Model#: CH120 Sku#: 578384 Internet#: 100052249 Eaton's Type CH circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). Our CH breakers are 3/4-in. wide and trip to the off position. They are available in 1, 2, or 3 poles from 10 to 150 Amp. In addition, arc fault and ground fault breakers are available in the Type CH line. Designed for applications up to 2,200-Watt, such as kitchen circuits, branch circuits, wall receptacles, dishwashers, refrigerators, freezers and washing machines HACR and SWD rated Use with type CH load centers only Solid and stranded wire can be used together Requires one 3/4 in. space
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Voltage Rating | 120V |
| MPN | CH120- |
| Suitable For | Interior |
| Control Style | Switch |
| Voltage | 120/240 VAC |
| Features | Plug-On Neutral |
| Room | Any Room |
| Item Width | 3/4" |
| Mounting Style | Clip-On |
| Maximum Amperage | 20 A |
| Color | Black |
| Current Rating | 16-30 A |
| Material | Plastic |
| Orientation | Vertical |
| Brand | Eaton |
| Operation Method | On/Off |
| Type | Circuit Breaker |
| Break Time | Instantaneous |
| Model | CH120 |
| Number Of Circuits | 1-10 |
| Application | Branch Circuit |
CH120 Eaton Circuit Breaker Type CH 1 Pole 20 Amp 3/4in 120v Eaton Circuit. Recommended for use with type CH load centers Works for up to 2,200-watt applications Ideal for protecting the wires from overheating Model#: CH120 Sku#: 578384 Internet#: 100052249 Eaton's Type CH circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). Our CH breakers are 3/4-in. wide and trip to the off position. They are available in 1, 2, or 3 poles from 10 to 150 Amp. In addition, arc fault and ground fault breakers are available in the Type CH line. Designed for applications up to 2,200-Watt, such as kitchen circuits, branch circuits, wall receptacles, dishwashers, refrigerators, freezers and washing machines HACR and SWD rated Use with type CH load centers only Solid and stranded wire can be used together Requires one 3/4 in. space
