CINCH JONES S-312-CCT-L POWER SOCKET 12PIN w/LATCH FOR DRAKE KENWOOD SWAN YAESU
NEW old stock 12 Pin Cinch Jones Socket S-312-CCT [Molex Beau S-3312-CCT 0380050044] connector with screw down strain relief and side latches. Eight blades are horizontal and four vertical to provide polarity. The connector can be wired as an AC or DC power cable. Fits radios such as the Drake TR4, Kenwood TS-520, Swan 350, Siltronix 1011, Yaesu FT-101, and others. The socket measures 1.25in(W) x 0.94in(H) x 1.69in (L) (including strain relief). NOTE: This connector is NOT compatible with the Yaesu FT-901 or FT-902 radios. See the S-321-CCT in listing # 400408698853 that can be modified to fit these radios. SPECIFICATIONS: * Polarized to prevent wrong-way insertion * Plugs have projecting flat blades, sockets have recessed twin blades * Plug prongs are .156" wide x .047"thick * Solder lugs terminals with wiring holes .093" x .062"* Molded monoblock phenolic, black * Black metal hood * Up to 150 degree Celsius * Plug 250 VAC RMS maximum* 10 Amps maximum Visit our eBay store for other radio accessories.
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Heat Shrink Ratio | n/a |
| Color | Black |
| MPN | S-312-CCT-L |
| Material | Metal |
| California Prop 65 Warning | www.p65warning.ca.gov |
| Brand | Cinch Jones |
| Type | Solder connector |
| Unit Type | Unit |
| Termination Type | Solder |
| Connector Style | 12 Pin |
| Model | S-312-CCT-L |
| Contact Material | Platted brass |
| Compatible Mounting Type | Cable |
| Country/Region Of Manufacture | Unknown |
NEW old stock 12 Pin Cinch Jones Socket S-312-CCT [Molex Beau S-3312-CCT 0380050044] connector with screw down strain relief and side latches. Eight blades are horizontal and four vertical to provide polarity. The connector can be wired as an AC or DC power cable. Fits radios such as the Drake TR4, Kenwood TS-520, Swan 350, Siltronix 1011, Yaesu FT-101, and others. The socket measures 1.25in(W) x 0.94in(H) x 1.69in (L) (including strain relief). NOTE: This connector is NOT compatible with the Yaesu FT-901 or FT-902 radios. See the S-321-CCT in listing # 400408698853 that can be modified to fit these radios. SPECIFICATIONS: * Polarized to prevent wrong-way insertion * Plugs have projecting flat blades, sockets have recessed twin blades * Plug prongs are .156″ wide x .047″thick * Solder lugs terminals with wiring holes .093″ x .062″* Molded monoblock phenolic, black * Black metal hood * Up to 150 degree Celsius * Plug 250 VAC RMS maximum* 10 Amps maximum Visit our eBay store for other radio accessories.
