CINCH JONES S-312-CCT POWER SOCKET 12PIN FOR DRAKE KENWOOD SILTRONIX SWAN YAESU
NEW 12 Pin Cinch Jones Socket S-312-CCT [Molex Beau S-3312-CCT] connector with screw down strain relief. Eight blades are horizontal and four vertical to provide polarity. The connector can be wired as an AC or DC power cable. Fits radios such as the Drake TR4, Kenwood TS-520, Swan 350, Siltronix 1011, Yaesu FT-101, and others. The socket measures 1.25in(W) x 0.94in(H) x 1.69in (L) (including strain relief). NOTE: This connector is NOT compatible with the Yaesu FT-901 or FT-902 radios. See the S-321-CCT in listing # 400408698853 that can be modified to fit these radios. SPECIFICATIONS: * Polarized to prevent wrong-way insertion * Plugs have projecting flat blades, sockets have recessed twin blades * Plug prongs are .156" wide x .047"thick * Solder lugs terminals with wiring holes .093" x .062"* Molded monoblock phenolic, black * Hood is thermoplastic * Up to 150 degree Celsius * Plug 250 VAC RMS maximum* 10 Amps maximum Visit our eBay store for other radio accessories.
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Color | Black |
| MPN | S-312-CCT |
| Material | Plastic |
| California Prop 65 Warning | www.p65warning.ca.gov |
| Brand | Molex or Cinch Jones |
| Type | Solder connector |
| Termination Type | Solder |
| Connector Style | 12 Pin |
| Contact Material | Nickel platted |
| Compatible Mounting Type | Cable |
| Country/Region Of Manufacture | Unknown |
NEW 12 Pin Cinch Jones Socket S-312-CCT [Molex Beau S-3312-CCT] connector with screw down strain relief. Eight blades are horizontal and four vertical to provide polarity. The connector can be wired as an AC or DC power cable. Fits radios such as the Drake TR4, Kenwood TS-520, Swan 350, Siltronix 1011, Yaesu FT-101, and others. The socket measures 1.25in(W) x 0.94in(H) x 1.69in (L) (including strain relief). NOTE: This connector is NOT compatible with the Yaesu FT-901 or FT-902 radios. See the S-321-CCT in listing # 400408698853 that can be modified to fit these radios. SPECIFICATIONS: * Polarized to prevent wrong-way insertion * Plugs have projecting flat blades, sockets have recessed twin blades * Plug prongs are .156″ wide x .047″thick * Solder lugs terminals with wiring holes .093″ x .062″* Molded monoblock phenolic, black * Hood is thermoplastic * Up to 150 degree Celsius * Plug 250 VAC RMS maximum* 10 Amps maximum Visit our eBay store for other radio accessories.
