FAST and SECURED shipping from our office in San Jose, California, with well-informed shipping time and tracking # by 2 emails: 1. Payment received. 2. Order status: time shipped out and tracking #.FEATURESCost-effective economy oscilloscope, 150MHz Bandwidth, 1GSa/s, 8M memory depth; with 1CH 25MHz waveform generator, support arbitrary waveform output; 14 kinds of trigger modes, standard with 5 kinds of serial protocol triggers and decodes; 32 kinds of auto measurements with statistics; 3-digit digital voltage meter and 6-digit hardware frequency indicator functions; 2 sets of DVM; Abundant SCPI remote command control. It is a useful commissioning instrument for various fields such as communication, aerospace, national defense, embedded systems, computers, research and education.1) 2 channels which are respectively controlled by independent knobs2) 100 MHZ and 150MHZ analog channel bandwidth3) Sampling rate up to 1 GSa/s4) 8M memory depth5) Vertical range 2mV/div ~ 10V/div6) Built-in 1 CH 25MHz waveform generator (DSO2D10, DSO2D15)7) Vertical resolution: 8bit8) Trigger: Edge, Pulse, Video, Slope, Overtime, Window, Pattern, Interval, Under Amp, UART, LIN, CAN, SPI, IIC9) BUS decode and protocol analysis: RS232/UART, I2C, SPI, CAN, LIN10) Can save multiple data formats, such as settings, waveforms, reference waveforms, CSV, pictures11) A 3-digit digital voltage meter and a 6-digit hardware frequency indicator12) 32 kinds of auto measurements with statistics, real-time statistics of maximum, minimum, standard deviation and etc.13) 2 sets of digital voltmeters14) Support threshold testing, free measurements within the screen15) Abundant SCPI remote command control16) USB Host/Device.Model Selection GuideModelChannelBandwidthSample RateMemory DepthAFG(Arbitrary Function Generator)DS02C102Ch100MHz1GSa/s8MSamplesN/ADS02C152Ch150MHz1GSa/s8MSamplesN/ADS02D102Ch + 1Ch100MHz1GSa/s8MSamples1ChDS02D152Ch + 1Ch150MHz1GSa/s8MSamples1ChSpecificationModelDSO2D15DSO2D10DSO2D15DSO2C10Bandwidth150MHz100MHz150MHz100MHzOscilloscope Channels2Ch2Ch2Ch2ChArbitrary Function Generator1Ch1Ch　　HorizontalSEC/DIV Range2ns/div to 100s/div, in a 1, 2, 5 sequenceDelta Time Measurement Accuracy(Full Bandwidth)Single, sampling mode± (1 sample interval + 100ppm × reading + 0.6ns)>16 times above average± (1 sample interval + 100ppm × reading + 0.4ns)Sample interval = s/div ÷ 200VerticalA/D Converter8-bit resolution, each channel sampled simultaneouslyVOLTS/DIV Range2mV/div to 10V/div at input BNCOffset Range2mV/div ~ 200mV/div, ±1V500mV/div ~ 10V/div, ±50VSelectable Analog Bandwidth Limit (Typical)20MHzLow Frequency Response (−3db)≤10Hz at BNCRising Time at BNC (Typical)DSO2C10 DSO2C15 DSO2D10DSO2D15≤3.5ns≤2.4ns≤3.5ns≤2.4nsDC Gain Accuracy±3% for Normal or Average acquisition mode, 10V/div to 10mV/div±4% for Normal or Average acquisition mode, 5mV/div to 2mV/divVertical Offset Accuracy±0.1div±2mV±1% OffsetMathematical Operation+, −, ×, /, FFTFFTWindow Function Types: Rectangle, Hanning, Hamming, Blackman, Bartlett and Flat TopVoltage Measurement Repeatability, Average Acquisition Mode Under the same setting and environment, ≥16 waveforms are sampled, ΔV of any two averages:± (3% × value + 0.05 div)Note: Bandwidth reduced to 6MHz when using a 1X probe AcquisitionSample Rate Range1GSa/s (single channel), 500MSa/s (dual channels)Acquisition ModesNormal, Peak, Average & High ResolutionWaveform Interpolation(sin x)/xAcquisition Rate (Typical)Up to 2000 waveform per second per channel (Normal acquisition mode, no measurement)Minimum Detection Pulse Width2nsSingle SequenceAcquisition ModeAcquisition Stop TimeNormal, Peak DetectUpon single acquisition on all channels simultaneouslyAverageAfter N acquisitions on all channels simultaneously, N can be set to 4, 8, 16, 32, 64 or 128Memory DepthMaximum 8M for single channel (4K, 40K, 400K, 4M, 8M optional)Maximum 4M for dual channels (4K, 40K, 400K, 4M optional)TriggerTrigger Type Edge, Pulse width, Video, Slope, Overtime, Window, Pattern, Interval, Delay, UART, LIN, CAN, SPI, lICTrigger Level Range±5 divisions from the center of the screenModeAuto, Normal, SingleLevelCH1 ~ CH2±5 divisions from the center of screenEXT0~3.3V [CMOS]Holdoff Range20ns ~ 10sTrigger Level AccuracyCH1~CH20.2 div × volts/div within ±4 divisions from the center of the screenEXT± (Set value × 6% + 40mV)Trigger Sensitivity±0.2divEdge TriggerSlopeRising, Falling, Rising & FalingSourceCH1 ~ CH2, Line, ExternalPulse Trigger Polarity Positive, NegativeCondition<，>，!=，=Source CH1 ~ CH2Pulse Width Range 8ns ~ 10sAccuracy8nsVideo Trigger Signal standard NTSC, PAL Signal sourceCH1 ~ CH2Synchronization ScanLine, LinrNum, OddField, EvenField and AllFieldSlope Trigger Slope Nse, FallCondition<, >, !=, =Source CH1 ~ CH2Time Range 8ns ~ 10sAccuracy 8nsOvertime TriggerSource CH1 ~ CH2,Polarity Positive, NegativeTime range 8ns ~ 10sAccuracy 8nsWindow Trigger Source CH1 ~ CH2Pattern TriggerPattern0: low level; 1: high level; X: ignore Level CH1 ~ CH2Interval TriggerSlopeRising, FallingCondition<, >, !=, =Signal Source CH1 ~ CH2Time Range 8ns ~ 10sAccuracy 8nsUnder Amp TriggerPolarity Positive, NegativeCondition <, >, !=, =Source CH1 ~ CH2Time Range 8ns ~ 10sAccuracy 8nsUART TriggerConditionStart, Stop, Data, Parity Error, COM ErrorSourceCH1 ~ CH2Data FormatHexCondition<, >, !=, =Data Length1 byteData Bits Width5 bit, 6 bit, 7 bit, 8 bitParity CheckNone, Odd, EvenIdle LevelHigh, LowBaud Rate (Selectable)110/300/600/1200/2400/4800/9600/14400/19200/38400/57600/115200/230400/380400/460400 bit/sBaud Rate (Custom)300bit/s ~ 334000bit/sLIN TriggerConditionInterval Field, Sync Field, Id field, Sync Id Error, Identifier, Id and DataSourceCH1 ~ CH2Data FormatHexBaud Rate (Selectable)110/300/600/1200/2400/4800/9600/14400/19200/38400/57600/115200/230400/380400/460400 bit/sBaud Rate (Custom)300bit/s ~ 334000bit/sCAN TriggerConditionStart Bit, Remote Frame, Data Frame Id, Frame Id, Data Frame Id A, Error Frame, All Error, Ack Error, Overload FrameSourceCH1 ~ CH2Data formatHexBaud Rate (Selectable)10000, 20000, 33300, 500000, 62500, 83300, 100000, 125000, 250000, 500000, 800000,1000000Baud Rate (Custom)5kbit/s ~ 1Mbit/sSPI TriggerSource (SDA/SCL)CH1 ~ CH2Data FormatHexData Length4, 8, 16, 24, 32IIC TriggerSource (SDA/SCL)CH1~CH2Data FormatHexData Index0~3ConditionStart Bit, Stop Bit, No Ack, Address, Restart, Address and DataInputNumber of Channels2 analog channelsInput CouplingDC, AC or GNDInput Impedance, DC Coupled20pF ± 3pF, 1MΩ ± 2%Probe Attenuation1X, 10XSupported Probe Attenuation Factors1X, 10X, 100X, 1000XOvervoltage Category300V CAT IIMaximum Input Voltage300VRMS (10X)Isolation Between Channels>40dBDelay Deviation Between Channels<500psMeasurementsCursorsVoltage difference between cursors: ΔVTime difference between cursors: ΔTReciprocal of ΔT in Hertz (1/ΔT)Automatic MeasurementsPkPk, Frequency, Average, Max, Min, Period, Vtop, Vmid, Vbase, Vamp, RMS, R-Overshoot, PeriodRms, F-Preshoot, PeriodRms, PeriodAvg, RiseTime, FallTime, +Width, −Width, +Duty,−Duty, FRR, FFF, F−Overshoot, R−preshoot, BWidth, FRF, FFR, LRR, LRF, LFR and LFFDVMData source CH1, CH2Measurement typeDC RMS, AC RMS, DCFrequency meter hardware 6 bits frequency meter Math OperationSourceCH1~CH2Operator+, −, x, /, FFTFFTPoint1024WindowRectangle, Hanning, Hamming, Blackman, Bartlett, FlattopDisplayShow only or show allVertical scaledB, VRmsStorageSave/Recall (Non-volatile)9 types of files can be saved and recalled internally, including settings, waveforms, and referencesSave to External MemoryCSV file, BMP picture (24 bit)Arbitrary Waveform GeneratorChannel 1Standard WaveformsSine, Square, Ramp, Exponential, Noise, DCSin Frequency range0.1Hz ~ 25MHzSquare / PulseFrequency range0.1Hz ~ 10MHzDuty1% ~ 99%Triangular Wave Frequency range0.1Hz ~ 1MHzRampFrequency range0.1Hz ~ 1MHzSymmetry0% ~ 100%ExponentialFrequency range0.1Hz ~ 5MHzNoise Bandwidth>25MHzDC offset Range±3.5V, high impedance ±1.75V, 50ΩResolution100µV or 3 bits, take the greater oneAccuracy2% (1kHz)Arbitrary waveformFrequency Range1µHz ~ 25MHzWave length4096Support PC download and external memory recallOutput impedance 50 Ω + 1%, high impedanceAmplitude Output range10mV ~ 7Vp-p (high impedance )5mV ~ 3.5Vp-p (50Ω)Amplitude accuracy±3dB　Waveform Depth 4KSaFrequency Resolution1uHzFrequency Accuracy <10KHz,100ppm>10KHz,50ppmModulationFMModulation waveformSine, square, rampModulation frequency1Hz ~ 50kHzModulation deviation0.1Hz ~ Carrier frequencyAMModulation waveformSine, square, rampModulation frequency1Hz ~ 50KHzModulation depth0% ~ 120%BurstTypes ofN Cycle, InfiniteNumber of cycles1 ~ 1024Trigger sourceManualTrigger Input Signal SourceLevelMOSProbe Compensator OutputOutput Voltage (Typical)5VFrequency (Typical)1kHz ± 1%DisplayDisplay Type7 inchs TFT (diagonal liquid crystal)Display Resolution800 (horizontal) × 480 (vertical) pixelsDisplay TypePoint, vectorWaveform BrightnessAdjustableGrid TypeAdjustableGrid BrightnessAdjustableScreen BrightnessAdjustableDisplay Colour16 million colours (24 bits true colour)Persistence timeMinimum, 1s, 5s, 10s, 30s, infiniteInterfaceStandard InterfaceUSB Host, USB DevicePower SupplySupply Voltage100 ~ 120VACRMS (±10%), 45Hz to 440Hz, CAT II120 ~ 240VACRMS (±10%), 45Hz to 66Hz, CAT IIPower Consumption<15WFuseT2A 250VAC 4*8EnvironmentalOperating Temperature0 to 50 °C (32 to 122 °F)Storage Temperature−40 to +71 °C (−40 to 159.8 °F)Humidity≤ +104°F (≤ +40°C): ≤90% relative humidityCooling Method106°F ~ 122°F (+41°C ~50°C): ≤60% relative humidityAltitudeOperating and Nonoperating3,000m (10,000 feet)Random Vibration0.31gRMS from 50Hz to 500Hz, 10 minutes on each axisNonoperating2.46gRMS from 5Hz to 500Hz, 10 minutes on each axisMechanical ShockOperating50g, 11ms, half sineMechanicalDimension 318 × 110 × 150mm (L × W × H)Weight1900g PAYMENTWe accept payments through PayPal and all major credit cards, including Visa, Master Card, American Express, and Discover.SHIPPINGFor your convenience, we utilize USPS, UPS, or FedEx for shipping, choosing the most cost-effective option or as per customers' specific requests.RETURN POLICY1. A 5% or 15% restocking fee applies to unopened or opened items, respectively.2. Items with marks or alterations cannot be accepted for return.3. Ensure items are returned with original packaging materials and accessories; otherwise, the refund amount may be reduced.4. Include a note inside the package indicating your eBay username, purchase date, and reasons for the return.5. Buyers are responsible for return shipping, and the original shipping fee will be deducted from the refund.CUSTOMER SERVICEOur dedicated staff is available for technical and sales inquiries via phone calls from 8am to 5pm PST (Pacific Standard Time). We strive to respond to eBay or email messages within 1 day. Your feedback and inquiries are important to us, so feel free to reach out.About this instrument: Our company, Analog Technologies, Inc., boasts 26 years of experience in designing and developing analog electronic products. The Oscilloscope offered has received widespread acclaim and recommendations from our customers' engineers. The user manual or datasheet can be conveniently found online or downloaded from our company's website. Your satisfaction with our products and services is paramount to our happiness.About us: Analog Technologies, Inc., established on January 7, 1997, as an R&D firm in Novi, Michigan, has expanded with branches in San Jose, California, USA; Sydney, Australia; and Anshan City, Liaoning Province, PR China. Our three departments - R&D, Production, and Marketing/Sales - work harmoniously towards our goal of customer satisfaction and the growth of our company. If you have any questions or suggestions, please do not hesitate to contact us. We aim to make our customers happy and continue growing into a larger entity.
