E6011 3/32" 5 lb Electrode Blue Demon
E6011 is a mild-steel, all position electrode designed primarily for use on AC power sources. It produces a strong arc force for deep penetration and a fine spray transfer that enhances operator appeal. Fast freezing or rapid solidification of the metal allows welding in the vertical and overhead position. Its light slag eliminates slag holes that are prevalent on some applications with other electrodes. This product can be suited in a wide range of applications. Typical Applications • General-purpose fabrication • Galvanized steel work • Structural work • Shipbuilding AWS Specification AWS A5.1/A5.1M:2004 AWS Classification E6011 Welding CurrentAC - DCEP Typical Wire Chemistry C 0.20 Mn 1.20 Si 1.00 P *N.S. S *N.S. Ni 0.30 Cr 0.20 Mo 0.30 V 0.08 Combined Limit for Mn+Ni+Cr+Mo+V *N.S. Typical Mechanical Properties (As Welded)Yield Strength, ksi 48 Tensile Strength, ksi 60 Elongation%, min 22 Welding Positions F,V,OH,H Available Diameters 3/32", 1/8", 5/32" & 3/16" Operating Range in Amps 3/32" 40 - 80 1/8" 75 - 125 5/32" 110 - 170 3/16" 140 - 215 *N.S. means Not Specified
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Length | 14 in |
| AWS Classification | E6011 |
| MPN | E6011-332-05P |
| Welding Rod Material | Carbon Steel |
| Brand | Blue Demon |
| Welding Rod Type | Arc Welding Rod |
E6011 is a mild-steel, all position electrode designed primarily for use on AC power sources. It produces a strong arc force for deep penetration and a fine spray transfer that enhances operator appeal. Fast freezing or rapid solidification of the metal allows welding in the vertical and overhead position. Its light slag eliminates slag holes that are prevalent on some applications with other electrodes. This product can be suited in a wide range of applications. Typical Applications • General-purpose fabrication • Galvanized steel work • Structural work • Shipbuilding AWS Specification AWS A5.1/A5.1M:2004 AWS Classification E6011 Welding CurrentAC – DCEP Typical Wire Chemistry C 0.20 Mn 1.20 Si 1.00 P *N.S. S *N.S. Ni 0.30 Cr 0.20 Mo 0.30 V 0.08 Combined Limit for Mn+Ni+Cr+Mo+V *N.S. Typical Mechanical Properties (As Welded)Yield Strength, ksi 48 Tensile Strength, ksi 60 Elongation%, min 22 Welding Positions F,V,OH,H Available Diameters 3/32″, 1/8″, 5/32″ & 3/16″ Operating Range in Amps 3/32″ 40 – 80 1/8″ 75 – 125 5/32″ 110 – 170 3/16″ 140 – 215 *N.S. means Not Specified
