FRN0072E2S-4GB 40 HP Fuji FRENIC-ACE Variable Frequency Drive, 3-Ph 380-480V In
FRN0072E2S-4GB 40 HP Fuji FRENIC-ACE Variable Frequency Drive, 3-Ph 380-480V In (3-Ph 380-480V Out, 72A Max) The FRENIC-Ace is a high performance, full-featured Drive designed to suit a wide variety of applications including fans, pumps, specialized machinery and more. Equipped with 200 steps of customizable logic and PMAC motor control, the FRENIC-Ace provides compact, but powerful multi-rated specification solutions for virtually all AC drive applications and comes standard with an industry-leading 3-year warranty. Specifications Nominal Motor HP [kW] 50 Hp [37 kW] (ND) 40 Hp [30 kW] (HD & HND) 30 Hp [22 kW] (HHD) Rated Output Capacity kVA 55 kVA (ND) 46 kVA (HD & HND) 34 kVA (HHD) Rated Output Voltage 3 Phase, 380-480 Volt (with AVR) Rated Output Current 72 Amps (HD) 60 Amps (HD & HND) 45 Amps (HHD) Rated Overload Capability 120 % of nominal current for 1 minute (ND & HND) 150 % of nominal current for 1 minute (HD) 150 % of nominal current for 1 minute or 200% of nominal current for 0.5 seconds (HHD) Main Power Supply Input 3 Phase, 380 to 480 Volt, 50/60 Hz (With AVR) Voltage / Frequency Variations Voltage: +10 % to -15% Voltage Unbalance: 2% or less Frequency: +5% to -5% Rated Current Input without DC Reactor [with DC Reactor] 94.3 Amps [68.5 Amps] (ND) 77.9 Amps [57 Amps] (HD & HND) 60.6 Amps [42.2 Amps] (HHD) Required Power Supply Capacity 47 kVA (ND) 39 kVA (HD & HND) 29 kVA(HHD) Braking Torque 12 % (ND) 15 % (HD & HND) 20 % (HHD) DC Braking Starting frequency: 0.0 to 60.0 Hz Braking Time: 0.0 to 30.0 Seconds Braking Level: 0 to 60 % (ND),0 to 80 % (HD & HND), 0-100 % (HHD) of nominal current Braking Chopper Built-In Braking Resister Optional Minimum Connectable Resistance 16 ? DC Reactor Optional DCR4-37C (ND) Optional, DC4-30B (HD & HND) Optional DCR4-22A (HHD) Cooling Fan Cooling Optional External Cooling Adapter PB-F1-30 EMC Filter Optional List Price $2,700.00 Dimensions 9.84" x 15.75" x 7.68" Weight 22 lbs Warranty 3 Years Environmental Enclosure IP20, UL Open Type UL Type 1 by Option Kit NEMA1-72E2-4 Ambient Temperature Standard (Open Type): -10 to +50 °C / 14 to 122 °F (HHD/HND) NEMA 1/UL Type 1: -10 to+40 °C / 14 to 104 °F (HHD/HND) Storage Temperature -25 to +65°C (-13 to 149 °F) Humidity 5 to 95% Relative Humidity (without condensation) Installation Location Indoors Altitude <3,300ft (1,000m) 1000-1500m .97 Output Current Derating Factor 1500-2000m .95 Output Current Derating Factor 2000-2500m .91 Output Current Derating Factor 2500-3000m .88 Output Current Derating Factor Codes and Standards UL / cUL 508C C22.2 No.14 CE RoHs GOST-R KC EN / ISOc13849-1:2008 cat. 3/PL:e Electrical Control V/F Control V/F Control with Slip Compensation Dynamic Torque Vector Control V/F Control with Encoder (Optional) Vector Control with Encoder (Optional) PM Motor Sensorless Vector Control Output Stability Analog setting: +/-0.2% of maximum frequency Digital setting: +/-0.01% of maximum frequency (by keypad settings) Output Frequency Max 500Hz Speed Control Range 1:1500 IM Vector Control w/encoder 1:100 IM V/F w/encoder 1:10 PM Sensorless Vector Control Digital Inputs (7) X1 - X5, FWD, & REV Programmable, 60 selectable functions Analog Inputs (1) -0 to +10Vdc (1) -4 to 20mA Digital Outputs (1) From C Relay (2) Transistor Output, 78 Selectable Functions Analog Output: Selectable Type (2) 0 to 10Vdc or 4 to 20mA, 19 Selectable Output Signal Functions. RS-485 Connections (2) RJ45 Port Terminal Operator's Keypad with LED Display Indicating System Operation and Associated Value Conversion, Status of I/O, Operations and Alarms Keypad Indications Operations, Number of times unit placed in operation, Duration and kWh output 24Vdc Output Terminal 100mA Maximum Supply * Normal Duty Heavy Duty High Carrier Frequency Normal Duty High Carrier Frequency Heavy Duty
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Power Rating | 18.5 KW |
| Input Frequency (Hz) | 50-60 ± 5% |
| Input Voltage | 200-240 VAC ± 10% |
| MPN | FRN0072E2S-4GB |
| Brand | Fuji |
| IP Rating | IP20 |
| Model | FRENIC-ACE |
| Country/Region Of Manufacture | Thailand |
| Output Frequency (Hz) | 0-500 |
| Number Of Phases | 3-Phase |
| Rated Load | 40 HP |
