weighing kit (NTEP) Legal for trade Full kit Build your own Floor scale 10000 LB
Floor Scale Kits - 5000 lb or 10,000 lb Indicator Specifications:Legal for Trade NTEP CC# 12-1120.5″ LED displayConfigurable A/D conversion ratepower for 8 350 ohm load cellsUnits: Lb / Kg / oz5 button operationSlave mode to use as remote display3 kinds of signal output for printers, Score boards & computers ( includes livestock auction mode) Comp ports: Rs-232 x1power: external AC/DC adapter & built-in rechargeable batteryStainless steel bracket for table stand or wall mountSize: 6.5″ x 3″ x 1.5″Features: Shear beam load cells, one end fixed.Alloy steel or Stainless Steel Option Self-centeringEasy to install & useShear Beam Single Ended Load Cellload cell Specifications:Rated Output (mV/V): 3.00±0.015Nonlinearity: ±0.02%FS Hysteresis: ±0.02%FS Repeatability: ±0.01%FS Creep (30 minutes): ±0.02%FS Zero Balance: ±1.00%FS Temperature Effect on Zero: ±0.02%FS/10°C Temperature Effect on Output: ±0.02%FS/10°C Input Resistance: 385±5Ω Output Resistance: 350±3Ω Insulation Resistance: ≥5000MΩ Excitation Voltage: 10V(DC/AC) Compensated Temperature Range: -10°C ~ 50°C Operating Temperature Range: -20°C ~ 60°C Safe Overload: 120%FS Cable: 5.4x6 m
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | MNM |
| Model | Weighing Kit |
| Features | A/C Power Adapter |
| MPN | PS-202 kit-10K |
Floor Scale Kits – 5000 lb or 10,000 lb Indicator Specifications:Legal for Trade NTEP CC# 12-1120.5″ LED displayConfigurable A/D conversion ratepower for 8 350 ohm load cellsUnits: Lb / Kg / oz5 button operationSlave mode to use as remote display3 kinds of signal output for printers, Score boards & computers ( includes livestock auction mode) Comp ports: Rs-232 x1power: external AC/DC adapter & built-in rechargeable batteryStainless steel bracket for table stand or wall mountSize: 6.5″ x 3″ x 1.5″Features: Shear beam load cells, one end fixed.Alloy steel or Stainless Steel Option Self-centeringEasy to install & useShear Beam Single Ended Load Cellload cell Specifications:Rated Output (mV/V): 3.00±0.015Nonlinearity: ±0.02%FS Hysteresis: ±0.02%FS Repeatability: ±0.01%FS Creep (30 minutes): ±0.02%FS Zero Balance: ±1.00%FS Temperature Effect on Zero: ±0.02%FS/10°C Temperature Effect on Output: ±0.02%FS/10°C Input Resistance: 385±5Ω Output Resistance: 350±3Ω Insulation Resistance: ≥5000MΩ Excitation Voltage: 10V(DC/AC) Compensated Temperature Range: -10°C ~ 50°C Operating Temperature Range: -20°C ~ 60°C Safe Overload: 120%FS Cable: 5.4×6 m
